Dongfeng VASOL EQ1160GL6DJ1 truck chassis CHINA 2022
- group name
- Trucks
- Min Order
- 1 piece
- brand name
- Yitongda China Used Cars for Sale
- model
- VASOL EQ1160GL6DJ1 truck chassis
- Nearest port for product export
- CHINA CN, CNNSA, CNSZN, CNTXG
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW
- Acceptable payment methods
- T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Westem Union, Cash, Escrow
- update time
- Wed, 04 Dec 2024 16:44:14 GMT
Paramtents
Total mass (Kg) 18000
Number of passengers allowed in the cab (person) 2,3
Wheelbase (mm) 4200,4400,3950,4500
Fuel type diesel oil
Maximum speed (Km/h) 88
Packging & Delivery
-
Min Order1 piece
Briefing
Detailed
Dongfeng VASOL EQ1160GL6DJ1 truck chassis
DONGFENG SPECIAL COMMERCLAL VEHICLE CO., LTD a wholly-owned subsidiary of Dongfeng Group, is an important unit of Dongfeng Group to carry the specialization, specialization, lightweight, electrification, intelligence, networking and sharing of commercial vehicles.
VASOL main business covers a full range of heavy, medium, light and micro tractors, engineering vehicles, trucks, special vehicles, special vehicles, new energy vehicles, etc. The products are widely used in the fields of highway transportation, engineering construction, municipal sanitation, special operations, etc.
VASOL has occupied the first place in the market for a long time in terms of training car, truck crane and truck crane.
Zhuzhou Yitongda acts as an agent to export high-quality used car products in China Dongfeng VASOL EQ1160GL6DJ1 truck chassis
|
Product trademark
|
VASOLDongfeng | Announcement batch | 355 |
|
Product name
|
Truck chassis | ||
|
manufacturing enterprise
|
Truck chassis | Kerb mass (Kg) | 4450,4680,4550 |
|
Total mass (Kg)
|
16000 | Total mass of trailer to be towed (Kg) | |
Overall dimension (mm) | 7200,7110,7800,7105,7185,7485,7500,7085,6795,6885×2380,2410,2280×2550,2520,2580,2620 | ||
Chassis category | Class II | Front overhang/rear overhang (mm) | 1300/1700,1300/1410,1300/1950,1300/2000,1285/1620,1285/1700,1285/1400,1285/1800,1300/1800,1285/1110,1285/1400 |
Number of passengers allowed in the cab (person) | 2,3 | Wheelbase (mm) | 4200,4400,3950,4500 |
Approach angle/departure angle (°) | 17/27,17/32,17/24 | Maximum speed (Km/h) | 88 |
Number of axles | 2 | Tyre specification | 9.00R20 |
Axle load (Kg) | 5600/10400 | Number of leaf springs | 9/11+8,9/10,9/11 |
Number of tyres | 6 | Rear track width (mm) | 1800,1820,1720 |
Approach angle/departure angle (°) | 17/27,17/32,17/24 | emission standard | GB17691-2018 Ⅵ |
Front track width (mm) | 1820,1920,1940 | ||
Fuel type | diesel oil | ||
remarks | 1. YCS04180-68 net power is 128kw, YCS04200-68 net power is 143kw, and YCS04160-68 net power is 114kw; 2. Optional lamps, bumpers, front covers, rearview mirrors and other new styles, optional chassis layout and tail lights; 3. Dimension correspondence (total length=front overhang+wheelbase+rear overhang): 7200=1300+4200+1700=1300+3950+1950,7110=1300+4400+1410,7800=1300+4500+2000,7105=1285+4200+1620,7185=1285+4500+1400=1285+4200+1700,7485=1285+4400+1800=1285+4500+1700,7500=1300+4200+2000=1300+4400+1700,7085=1285+4400+1100,6885=1285+4200+1400+1400; 4. ABS model and manufacturer: 3631010-C2000/East Knorr-Bremse Commercial Vehicle Brake System (Shiyan) Co., Ltd., J ABS/Jiaozuo Borak Control Technology Co., Ltd; 5. The vehicle model can be equipped with ETC on-board device; 6. The chassis layout such as battery frame/air reservoir/urea tank/diesel filter is optional, the side spare tire is optional, and the silver (black) rim/tire rim is optional; 7. Select and install new style cab drawing and decoration | ||
Engine model | Engine manufacturer | Displacement (ml) | Power (Kw) |
YCS04180-68 | Guangxi Yuchai Machinery Co., Ltd | 4156 | 132 |
YCS04200-68 | Guangxi Yuchai Machinery Co., Ltd | 4156 | 147 |
YCS04160-68 | Guangxi Yuchai Machinery Co., Ltd | 4156 | 118 |
