VASOL DFD5316GJBL6D11 concrete mixer truck CHINA 2022
- group name
- Building Machinery
- Min Order
- 1 piece
- brand name
- Yitongda China Used Cars for Sale
- model
- VASOL DFD5316GJBL6D11 concrete mixer truck
- Nearest port for product export
- CHINA CN, CNNSA, CNSZN, CNTXG
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW
- Acceptable payment methods
- T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Westem Union, Cash, Escrow
- update time
- Wed, 25 Dec 2024 02:54:23 GMT
Paramtents
Total mass (Kg) 3100
Number of passengers allowed in the cab (person) 2
Wheelbase (mm) 1950+2900+1350
Fuel type diesel oil
Maximum speed (Km/h) 88
Packging & Delivery
-
Min Order1 piece
Briefing
Detailed
VASOL VASOL DFD5316GJBL6D11 concrete mixer truck
DONGFENG SPECIAL COMMERCLAL VEHICLE CO., LTD a wholly-owned subsidiary of Dongfeng Group, is an important unit of Dongfeng Group to carry the specialization, specialization, lightweight, electrification, intelligence, networking and sharing of commercial vehicles.
VASOL main business covers a full range of heavy, medium, light and micro tractors, engineering vehicles, trucks, special vehicles, special vehicles, new energy vehicles, etc. The products are widely used in the fields of highway transportation, engineering construction, municipal sanitation, special operations, etc.
VASOL has occupied the first place in the market for a long time in terms of training car, truck crane and truck crane.
Zhuzhou Yitongda acts as an agent to export high-quality used car products in China VASOL DFD5040XXYLBEV1 pure electric van
|
Product trademark
|
VASOL | Announcement batch | 363 |
|
Product name
|
Concrete mixer truck | Product model | DFD5316GJBL6D11 |
|
Total mass (Kg)
|
31000 | Tank volume (m3) | 7.96 |
|
Rated load capacity (Kg)
|
17270 | Overall dimension (mm) | 10100×2500×3995,3955 |
Kerb mass (Kg) | 13500 | Cargo box size (mm) | |
Number of passengers allowed in the cab (person) | 2 | Maximum load capacity of saddle (Kg) | |
Approach angle/departure angle (°) | 16/25,14/26 | Front overhang/rear overhang (mm) | 1410/2490 |
Axle load (Kg) | 6500/6500/18000 (two-shaft group) | Maximum speed (Km/h) | 88 |
remarks | 1. Tank agitation capacity 7.96 m3, total tank length (including head): 6050mm, maximum diameter φ 2180mm, head length 220mm, tank installation angle 14.5 degrees; 2. Protective device material: Q235; Connection mode: connected with frame bolts; Section dimension of rear guard 120 × 60mm, 480mm, 460mm, 440mm, 430mm above the ground; 3. The vehicle is equipped with a travel recorder with satellite positioning function; 4. ABS model and manufacturer: 3631010-C2000/East Knorr-Bremse Commercial Vehicle Brake System (Shiyan) Co., Ltd., J ABS/Jiaozuo Borak Control Technology Co., Ltd., ABS-E 4S/4M/Weibeco Automotive Control System (China) Co., Ltd; 5. The corresponding fuel consumption of engine WP8.350E61A is 36.8L/100km; 6. The vehicle model can be equipped with ETC on-board device; 7. Choose the style and decoration of the new style granola; 8. Optional after-treatment heat shield; 9. Optional rear ladder structure, optional tank color and painting | ||
Chassis Model | DFD5316GJBL6DJ1 | Chassis name | Concrete mixer truck chassis |
Trade name | VASOL | manufacturing enterprise | Dongfeng Motor Group Co., Ltd |
Number of axles | 4 | Number of tyres | 12 |
Wheelbase (mm) | 1950+2900+1350 | ||
Tyre specification | 11.00R20 18PR,295/80R22.5 16PR,295/80R22.5 18PR | ||
Number of leaf springs | 9/9/13,3/3/4 | Front track width (mm) | 2020/2020,2000/2000 |
Fuel type | diesel oil | Rear track width (mm) | 1860/1860 |
Emission standard | |||
Engine model | Engine manufacturer | Displacement (ml) | Power (Kw) |
WP8.350E61A | Weichai power company limited | 7800 | 257 |
